The Dimplex Revillusion^® is a completely new way of looking at fireplaces, and changing the standard for electric. A clear view through the lifelike flames, to the full brick or concrete interior, captures the charm of a wood-burning fireplace. Enjoy the look of a fireplace cut straight from the pages of a magazine by choosing Revillusion^®; clearly a better fireplace.

Included Accessories:

The Revillusion comes with a log set, glass pane, plug accessory kit, and remote control

Features

Flames are larger, brighter and more random, appearing from within the logs.
Partially frosted acrylic panel is clearly better than a mirror, showing only dazzling flames and no reflections.
See clear through the flames to the back of the firebox for a more authentic experience.
Customize the firebox glow with a choice of warm hues, plus midnight mode.
Adjust the flame base color to red or blue.
A full grate of life-size hardwood-cast logs, tiered for greater depth.
Full Brick-surround Firebox - More authentic day or night; 270-degree herringbone brick with natural soot markings.
Adjust light level to suit the room and choose flicker effect for enhanced firelight.
Automatically adjusts firebox light to suit the room day to night.
Simply frame, wire and finish – no venting, gas lines or safety screens.
Option to use 240 volt supply for up to 8,800 BTU - use as part of primary heating plan; heater also operates without flame and can be deactivated.
Enjoy the unique charm of a fireplace 365 days a year using the flames without the heat.
Designed to be direct-wired to a 120, 208 or 240 volt circuit for a seamless look (optional plug kit available).
The most sustainable fireplace option

Specs

Volts	120/208/240 V
Watts	1300/1975/2575 W
Amps	10.8/9.4/10.7
Height, Width,Depth	26 5/8 x 37 1/4 x 12 1/8"
Gross Weight	74.4 lbs
BTU	4400/6745/8794

Warranty

The Dimplex product includes a 2 year limited warranty covered by the manufacturer.

Manuals

Dimplex Installation Manual for Revillusion Series Firebox
