England's Stove Work Blue Ridge 500-I Wood Stove ESW0014

High efficiency 3.5 ft³ firebox
Up to 10 hours burn time
Spring faceplate adjustment system which easily adapts to any type of hearth
Steel top reinforced with a stainless steel heat shield
Cast iron door and ceramic glass
EPA certified
Proudly made in USA
Non-catalytic combustion system
Qualifies for the 30% US tax credit
Included: 32" x 50" faceplate, air intake damper and 144 CFM blower with thermodisc

Fuel type	Dry cordwood (16" recommended)
Recommended heating area	1,000 - 2,700 ft²
Overall firebox volume	3.5 ft³
EPA loading volume	2.88 ft³
Maximum burn time	10 h
Maximum heat output-dry cordwood	110,000 BTU/h (32.2 kW)
Minimum overall heat output rate	17,200 BTU/h (5.0 kW)
Maximum overall heat output rate	57,800 BTU/h (16.9 kW)
Average overall efficiency-dry cordwood (HHV)	71 %
Average overall efficiency-dry cordwood (LHV	76 %
Optimum efficiency	77 %
Optimum heat transfer efficiency	75 %
Average particulate emission rate	1.6 g/h
Average CO	73 g/h

Mobile home approved	No
Premium quality blower included (CFM)	144
Certified according to applicable standards	CAN/USA accredited laboratory
Combustion technology	Non-catalytic
Stainless-steel secondary-air system	Yes
Flue outlet diameter	6"
Distance-center of the flue outlet to back unit	7 1/8"
Distance-center of the flue outlet to side unit	14 3/8"
Recommended chimney diameter	6"
Type of chimney	Liner ULC-S635, CAN/ULC-S640, UL 1777
Minimum chimney height	12'
Overall dimension (Width)	50"
Overall dimension (Height)	32"
Overall dimension (Depth)	28 7/8"
Door type	Single, glass with cast iron frame
Door opening size (Width)	19"
Door opening size (Height)	10 5/8"
Glass type	Ceramic glass
Glass surface - W x H	16 5/8" x 11 3/4"
Steel thickness-body	3/16"
Steel thickness-top	3/8"
Firebox size (Width)	22 7/8"
Firebox size (Height)	13"
Firebox size (Depth)	20 1/8"
Maximum log length	22" oriented East-West
Log positioning	Loading over width and over depth
Firebox lined with refractory bricks	Yes
Baffle type	High quality vermiculite
Minimum fireplace opening (Width)	31"
Minimum fireplace opening (Height)	26 1/4"
Minimum fireplace opening (Depth)	18 3/8"
High-efficiency certified appliance	Yes, EPA 2020 approved
Canadian Standard (emissions)	CSA B415.1-10
USA Standard (emissions)	EPA
Canadian Standard (safety)	ULC S628
USA Standard (safety)	UL 1482, UL 737
Warranty	Limited 5 years
Shipping weight	520 lb (236 kg)

CLEARANCE	SINGLE WALL PIPE	DOUBLE WALL PIPE
Base of the unit to ceiling		84"

Country
